- 8 Digital Inputs/Outputs
- Control any input or output from TTL to high voltage high current industrial devices
- Factory floor process control and automation
- User friendly software interface, Legacy compatible
- 0°C to +60°C Temperature range, Wall mountable
- Software APIs for Visual Basic, C# and more
Ethernet To Serial Port
Description
Ethernet to DIO device: 8 digital input/output channels. Powerful ARM 80 MHz, 32 Bit CPU. Offers robust and intelligent 'control side' devices that provide the interface to systems on the 24V factory floor environment, commonly referred to as 'process side'. The device installs as a COM Port on the PC to give complete backwards compatibility essential for legacy applications.
Typical applications are control and switching of AC and DC motors, Fans, relay drivers, pumps, Voltage Regulators and Battery Chargers, LEDs and Bulbs, Air Conditioning, Heaters and Solenoids..
Customer Feedback
I wish I had discovered this product a year ago!
John Towersey, MechlineGreat products. Excellent quality.
ENZ Engineering, BerlinPowerful and easy to use .COM Interface
MiE (Medical Imaging Electronics)Quite happy with my ED-008 so far. It was easyto set up. Relatively good docs. Code samples were greatly appreciated.
VOIP-4U LtdGreat products and brilliant to see still manufactured inUK
AI AutomationFantastic job keep up the good work!
Vibra-TechnicsEthernet To Serial Converter
I've purchased a number of these now and haven't had a problem with any of them.
Somfy Projects ‹›Product Videos
Operating Systems
Tech Spec
| IO Channels | |
| IO Protocols | Modbus TCP or DCON ASCII (over TCP or Virtual COM port) |
| Description | 8 Digital Inputs/Outputs |
| Digital Inputs | 8 |
| Digital Outputs | 8 |
| Analog Inputs | 0 |
| Analog Outputs | 0 |
| Watchdog | When device comms is lost, outputs can be set to predetermined state |
| Power On Values | Outputs can be set to predetermined values on power on |
| Safe Values | When Input triggered, outputs can be automatically set to predetermined value |
| Digital IO | |
| Input Logic Level 0 | 0.0V to +1.0V |
| Input Logic Level 1 | +2.0V to +30V |
| Input Latches | Triggered by user programmable positive or negative edges, stays true until acknowledged |
| Input Counter | User progammable- counts positive or negative transitions up to 200Hz |
| Digital Output Type | Open drain transistor, protected MosFET. Short circuit protection up to 36V. Over temperature shutdown -175°C typical 150°C min |
| Maximum Output Load Voltage | 30 VDC |
| Maximum Output Current Sink | 0.85A per channel |
| Serial Port | |
| Serial Gateway | No |
| Protocol | RS232 |
| Network | |
| Number of Ports | 1 |
| Network Port Type | RJ45 Jack 10/100 MHz Autosensing, Cross Over Autosensing (MDIX) |
| Network Protocols | ICMP, IP, TCP, DHCP, HTTP |
| Protection | 1500V Magnetic Isolation between ports and network |
| Power | |
| Power Input | 5V - 30V DC input, reverse polarity protected |
| Power Supply 1 Description | Global Power Supply - PW-600 |
| Power Supply 2 Description | Power supply PW-650 |
| Max Input | 35 Volts |
| General | |
| Operating Temperature Range | 0 °C to +60 °C / 32 °F to +140 °F |
| Industrial Standard | No |
| Storage Temperature | 0 °C to +70 °C / +32 °F to +158 °F |
| Galvanic Isolation | No |
| Power Consumption | [email protected] 2.5W max |
| Product Weight | 0.127 kg, 4.48 ounces |
| Product Dimensions | 116x100x26 mm, 4.6x3.9x1.0 inches |
| Packaged Weight | 0.223 kg, 7.87 ounces |
| Packaged Dimensions | 160x135x49 mm, 6.3x5.3x1.9 inches |
| GTIN (barcode) | 837324009811 |
| Operating System Compatibility | |
| Operating Systems |
|
Approvals
Microsoft Signed Drivers
Microsoft Hardware
Related Products
| ED-008 | ED-204 | ED-004 | ED-038 | ED-588 |
| Ethernet to 8 Digital IO Lines | Ethernet to 4 Digital IO and RS232 Serial Port with Ethernet Switch | Ethernet to 4 Digital IO and RS232 Serial Port | Ethernet to 3 Relay + 3 Digital In | Ethernet to 8 Digital Inputs and 8 Digital Outputs + RS485 Gateway |
Modbus TCP or DCON ASCII (over TCP or Virtual COM port) 8 Digital Inputs/Outputs 8 8 0 0 No RS232 No | Modbus TCP or DCON ASCII (over TCP or Virtual COM port) 4 Digital Inputs/Outputs 4 4 0 0 True serial port: RS232/422/485 RS232 No | Modbus TCP or DCON ASCII (over TCP or Virtual COM port) 4 Digital Inputs/Outputs 4 4 0 0 True serial port: RS232/422/485 RS232 No | Modbus TCP or DCON ASCII (over TCP or Virtual COM port) 3 Digital Inputs and 3 Relays 3 3 Relays 0 0 No RS485 No | Modbus TCP or DCON ASCII (over TCP or Virtual COM port) 8 Digital Inputs and 8 Digital Outputs 8 8 0 0 RS485 NuDam/ADAM compatible expansion port Yes |
| £ 99.00 (gbp) | £ 149.00 (gbp) | £ 125.00 (gbp) | £ 115.00 (gbp) | £ 189.00 (gbp) |
